SF75 — Highly Insulated Aluminum Folding Sliding Doors
The worldwide best insulated aluminum folding door SF75 is the best system to meet the highest demands for thermal insulation. This folding door offers the best insulating values! Benefits from both maximum energy savings and slim profile designs.
All aluminum folding sliding door systems are designed for application with a low thermal performance profile.
Most common applications are:
High Insulation Applications
Exterior Space Enclosure
Stadium Press Boxes/Owner Suites
Hospitality Space Management
Restaurants
Bar / Counter Enclosures
Residential Patio Doors
etc.
-
High Insulation Applications
Exterior Space Enclosure
Stadium Press Boxes/Owner Suites
Hospitality Space Management
Restaurants
Bar / Counter Enclosures
Residential Patio Doors
etc.
-
The inner and outer rubber gaskets close tightly against the tracks and leave the noises and the weather outside. Additional safety and operational features generate peace of mind.
-
Our standard painting procedures are powder coating and anodization.
Both procedures allow a large variety of colors or effects to be achieved.
Anodized finishes can get pre-treatments like polishing or brushing the extrusions to achieve the perfect look.
Powder coatings can be flat, glossy, smooth, textured and pre-treated for marine environments.
Wood grain effects are also available for the aluminum extrusions.
FULL Standard RAL or NCS color ranges are available, beside of custom mixtures and color to match a sample provided. -
DP +/- 60 psf rated and tested in accordance with AAMA/WDMA/CSA 101/I.S.2/A440-05 (Typical Test Specimen Size: 3 panel unit 96” w x 96” h Overall)
Air infiltration ASTM E283-04
Test Results for inswing unit:
Test Pressure +1.57 psf = 0.24 (ft3 /min- ft2)
Test Results for out-swing unit:
Test Pressure +1.57 psf = 0.29 (ft3 /min- ft2)
Test Pressure +6.24 psf = 0.67 (ft3 /min- ft2)Uniform static air pressure ASTM E330-02
Water Infiltration ASTM E331 = 9 psf (inswing and outswing)
Sound transmission control = STC 36 dB (with 36 dB glass)
= STC 36 dB (with 36 dB glass)
Forced Entry ASTM F588, AAMA 1302.5 & 1303.5
Burglar-proof PA 202 to resistance class 2 (WK2)
-
Basic Size Limitations:
System Panel Width: Max. 47" (1200 mm)
System Height: Max. 12' (3600 mm)
Panel Weight: 176 lbs/panel (80 kg/panel)Available Options:
The options list is almost endless, since we can upgrade our products to almost all customer needs.
Just to name a few options:
- Egress door hardware
- Locksets as needed
- Door closers
- Custom handle solutions
- Thousands of Glass types available
- Different Track Types (raised sill, recessed flush sill,...)
- midrails, muntins,...
- matching fixed, tilt, turn or tilt and turn windows/doors
