Auto-Set® Model FSFD-IS
FIRE RATEDSMOKE RATEDVERTICAL ACTING
The FSFD-IS is designed for interior or exterior applications where fire protection is necessary and climate and temperature control are also critical.
Available with an R value up to 9.3, the highest in the industry.
The model FSFD-IS is designed for openings which are exposed to the elements of nature. Climatic control of building areas or building separations while maintaining the fire rating that is required for a facility.
-
Up to 4-hour rated UL 10B*
Smoke & Draft labeled UL 1784
Thermal protection with an R value up to 9.3
*Listed under the Canadian equivalent CAN/ULC S104
-
— CCRR-1086
-
Not applicable
-
Auto-Set® automatic resetting
Fail-Safe Design – automatic self-closing mechanism does not require power operation
Based upon door size, available with hand-chain or hand-crank operation
-
Unlimited heights and widths to 80′; for larger sizes and custom configurations consult the factory
-
McKEON Sterling Gray
Powder coat of any color as selected
Stainless Steel — No. 4 Polish or No. 8 Mirror
This technology is the subject of US Patent No. 8,453,707.
